Attachments let you log binary data like images, audio, video, PDFs, and large JSON objects alongside your traces. This enables multimodal evaluations, preserves visual context, and handles data structures that exceed standard trace limits.

​
Upload files

In addition to text and structured data, Braintrust supports uploading file attachments (blobs). This is especially useful when working with multimodal models, which can require logging large image, audio, or video files. You can also use attachments to log other unstructured data related to your LLM usage, such as a user-provided PDF file that your application later transforms into an LLM input. To upload an attachment, create a new Attachment object to represent the file on disk or binary data in memory to be uploaded. You can place Attachment objects anywhere in the event to be logged, including in arrays/lists or deeply nested in objects. See the TypeScript or Python SDK reference for usage details.
import { Attachment, initLogger } from "braintrust";

const logger = initLogger({ projectName: "My Project" });

logger.log({
  input: {
    question: "What is this?",
    context: new Attachment({
      data: "path/to/input_image.jpg",
      filename: "user_input.jpg",
      contentType: "image/jpeg",
    }),
  },
  output: "Example response.",
});
The SDK uploads the attachments separately from other parts of the log, so the presence of attachments doesn’t affect non-attachment logging latency. Screenshot of attachment list in Braintrust Image, audio, video, and PDF attachments can be previewed in Braintrust. All attachments can be downloaded for viewing locally.

​
Log large JSON data

Braintrust has a 20MB limit per span on individual logging upload requests. However, you may need to log larger data structures, such as lengthy conversation transcripts, extensive document sets, or complex nested objects. The JSONAttachment allows you to upload JSON data inline, and it will automatically get converted to an attachment behind the scenes. When you use JSONAttachment, your JSON data is:
  • Uploaded separately as an attachment, bypassing the 20MB per-span limit
  • Not indexed, which saves storage space and speeds up ingestion, but not available for search or filtering
  • Still fully viewable in the UI with all the features of the JSON viewer (collapsible nodes, syntax highlighting, etc.)
This approach is ideal for data that you want to preserve for debugging but don’t need to search across traces.

​
Basic example

import { JSONAttachment, initLogger } from "braintrust";

const logger = initLogger({ projectName: "My Project" });

// Large conversation transcript
const transcript = Array.from({ length: 100 }, (_, i) => ({
  role: i % 2 === 0 ? "user" : "assistant",
  content: `Message content ${i}...`,
  timestamp: new Date().toISOString(),
}));

logger.log({
  input: {
    transcript: new JSONAttachment(transcript, {
      filename: "conversation_transcript.json",
      pretty: true, // Optional: pretty-print
    }),
  },
  output: "Conversation completed",
});

​
Advanced examples

For more complex use cases, JSONAttachment can handle large document collections with embeddings, system configurations, and other nested data structures. These examples show realistic scenarios where you might need to log data structures that exceed standard size limits.
import { JSONAttachment, initLogger } from "braintrust";

const logger = initLogger({ projectName: "My Project" });

// Example: Large document collection
const documents = Array.from({ length: 500 }, (_, i) => ({
  id: `doc_${i}`,
  title: `Document ${i}`,
  content: `This is a long document with lots of text content...`.repeat(100),
  metadata: {
    author: `Author ${i % 20}`,
    created_at: new Date(Date.now() - i * 3600000).toISOString(),
    tags: [`tag_${i % 10}`, `category_${i % 5}`],
    embeddings: Array.from({ length: 768 }, () => Math.random()),
  },
}));

logger.log({
  input: {
    query: "Find documents about machine learning",
    search_context: new JSONAttachment(documents, {
      filename: "document_collection.json",
      pretty: true, // Optional: pretty-print the JSON
    }),
    search_params: {
      limit: 10,
      similarity_threshold: 0.8,
    },
  },
  output: {
    results: documents.slice(0, 10).map((d) => ({ id: d.id, title: d.title })),
    total_searched: documents.length,
  },
  metrics: {
    search_duration_ms: 1250,
    documents_processed: documents.length,
  },
});

// Example: Complex nested configuration
const systemConfig = {
  models: Array.from({ length: 50 }, (_, i) => ({
    id: `model_${i}`,
    name: `Model ${i}`,
    parameters: {
      temperature: Math.random(),
      max_tokens: 1000 + i * 100,
      top_p: 0.9,
      frequency_penalty: Math.random() * 0.5,
      presence_penalty: Math.random() * 0.5,
    },
    performance_metrics: {
      latency_p50: Math.random() * 1000,
      latency_p95: Math.random() * 2000,
      latency_p99: Math.random() * 3000,
      success_rate: 0.95 + Math.random() * 0.05,
    },
  })),
  prompts: Array.from({ length: 100 }, (_, i) => ({
    id: `prompt_${i}`,
    template: `System prompt template ${i} with lots of instructions...`.repeat(
      50,
    ),
    version: `v${i}.0.0`,
    test_cases: Array.from({ length: 20 }, (_, j) => ({
      input: `Test input ${j}`,
      expected: `Expected output ${j}`,
    })),
  })),
};

logger.log({
  input: {
    experiment_name: "model_comparison",
    config: new JSONAttachment(systemConfig, {
      filename: "experiment_config.json",
    }),
  },
  output: {
    best_model: "model_42",
    summary: "Completed comparison of 50 models across 100 prompts",
  },
});
External attachments are only supported in self-hosted deployments, not in Braintrust cloud.
Reference files in external object stores (currently S3 only) without uploading them:
import { ExternalAttachment, initLogger } from "braintrust";

const logger = initLogger({ projectName: "My Project" });

logger.log({
  input: {
    document: new ExternalAttachment({
      url: "s3://my-bucket/path/to/file.pdf",
      filename: "file.pdf",
      contentType: "application/pdf",
    }),
  },
  output: "Document processed",
});
Custom view PDF limitation: PDF files referenced as ExternalAttachment objects cannot be rendered in custom views due to browser-level security restrictions in the sandboxed iframe environment. While images and videos work correctly, browsers block PDF rendering in this context.To display PDFs in custom views, upload them as standard Attachment objects or host them externally and link to them instead of attempting inline rendering.

​
Inline attachments

Sometimes your attachments are pre-hosted files which you do not want to upload explicitly, but would like to display as if they were attachments. You can log external images and files in several ways:

​
Simple URLs and base64 strings

To log an external image, simply provide an image URL, an external object store URL, or a base64 encoded image as a string. The tree viewer will automatically render the image. The tree viewer will look at the URL or string to determine if it is an image. If you want to force the viewer to treat it as an image, nest it in an object like this:
{
  "image_url": {
    "url": "https://example.com/image.jpg"
  }
}
Base64 images must be rendered in URL format, just like the OpenAI API:

​
Structured inline attachments

If your image’s URL does not have a recognized file extension, it may not get rendered as an image automatically. In this case, you can use a structured inline attachment format to force it to be rendered correctly. Create a JSON object anywhere in the log data with type: "inline_attachment" and src and content_type fields. The filename field is optional.
{
  "file": {
    "type": "inline_attachment",
    "src": "https://robohash.org/example",
    "content_type": "image/png",
    "filename": "A robot"
  }
}
Custom views automatically handle signing for uploaded attachments, inline attachments, and external attachments. When you fetch span data in a custom view, these attachment URLs are pre-signed and ready to render. However, PDF files have browser-level restrictions that prevent rendering in custom views. See Render attachments in custom views for examples and details.

​
Read attachments via SDK

You can programmatically read and process attachments using the Braintrust SDK. This allows you to access attachment data in your code for analysis, processing, or integration with other systems. When accessing a dataset or experiment, the TypeScript and Python SDKs automatically create a ReadonlyAttachment object for each attachment. For attachments in scorers or logs, use the ReadonlyAttachment class to access attachment data, check metadata, and process different content types.
import { initDataset } from "braintrust";
import { Buffer } from "buffer";

async function processDatasetWithAttachments() {
  // Load a dataset that contains attachments
  const dataset = initDataset({
    project: "my-project",
    dataset: "my-dataset-with-images",
  });

  // Get the single row from the dataset
  const records = dataset.fetch();
  const row = await records.next();
  const record = row.value;

  // The record contains attachment references that are automatically converted to ReadonlyAttachment objects
  const imageAttachment = record.input.image;
  const documentAttachment = record.input.document;

  // Access image attachment data
  const imageData = await imageAttachment.data();

  // Process the image data
  const arrayBuffer = await imageData.arrayBuffer();
  const buffer = Buffer.from(arrayBuffer);

  // Access document attachment data
  const documentData = await documentAttachment.data();
  const documentText = await documentData.text();
}

processDatasetWithAttachments();

import { ReadonlyAttachment } from "braintrust";
import { Buffer } from "buffer";

async function processRawLogsWithAttachments() {
  // Example raw log data that contains attachment references
  const rawLogData = {
    id: "log-123",
    input: {
      question: "What is in this image?",
      image: {
        type: "braintrust_attachment" as const,
        key: "attachments/abc123def456",
        filename: "sample_image.jpg",
        content_type: "image/jpeg",
      },
      document: {
        type: "braintrust_attachment" as const,
        key: "attachments/xyz789ghi012",
        filename: "context.pdf",
        content_type: "application/pdf",
      },
    },
    output: "This image shows a cat sitting on a windowsill.",
  };

  // Manually create ReadonlyAttachment objects from raw attachment references
  const imageAttachment = new ReadonlyAttachment(rawLogData.input.image);
  const documentAttachment = new ReadonlyAttachment(rawLogData.input.document);

  // Access image attachment data
  const imageData = await imageAttachment.data();

  // Process the image data
  const arrayBuffer = await imageData.arrayBuffer();
  const buffer = Buffer.from(arrayBuffer);

  // Access document attachment data
  const documentData = await documentAttachment.data();
  const documentText = await documentData.text();
}

processRawLogsWithAttachments();
Work with external attachments (like S3 files) using the same patterns.
import { ReadonlyAttachment } from "braintrust";
import { Buffer } from "buffer";

async function processExternalAttachment() {
  // Example external attachment reference
  const externalAttachment = new ReadonlyAttachment({
    type: "external_attachment" as const,
    url: "s3://bucket/path/to/file.pdf",
    filename: "document.pdf",
    content_type: "application/pdf",
  });

  // Access external attachment data
  const data = await externalAttachment.data();
  console.log(`External file size: ${data.size} bytes`);

  // Convert Blob to Buffer for file writing
  const arrayBuffer = await data.arrayBuffer();
  const buffer = Buffer.from(arrayBuffer);

  // Save to local file
  console.log("External attachment ready for processing");
}

processExternalAttachment();

​
